Packaging & Shipping
♦ Entry/Exit Station—Foam cotton+carton+wooden case
♦ Barrier Gate—Foam cotton+carton+wooden case
♦ Boom Arm—Foam cotton + wooden case
Product Description
How does it work:
Hourly parkers :ENTRY : Hourly parkers press the button of the Entry station automatically dispense card, the entry barrier gate open.EXIT : Hourly parker comes to manual pay station, gives card to guard and payment.EXIT : After payment, Hourly parker comes to the exit station to insert the ticket and barrier gate open.
Season parkers with Long Range RFID :
ENTRY : Reader reads tag, barrier opens.
EXIT : Reader reads tag, barrier opens, creates billing record.
Other Season parkers :
ENTRY : Season parker swipe proximity card onto entry station, barrier open.
EXIT : Season parkers swipe proximity card onto exit station, barrier open.
Specifications
| Display Specification | LCD display with 8 inch |
| Cabinet material | SPCC 2.0mm |
| Communicate Port | TCP |
| Apply tempeture | -40℃~+80℃ |
| Relative humidity | 10%~+95% |
| Cards type | IC/Ticket/ID |
| Entry Terminal accessories | Card/Ticket dispenser, LCD display, IC card reader, loop detector, power supply. |
Advantages
1. Smooth design lines, simple and elegant, with black imported tempered acrylic, low profile luxury, stylish, durable, wear-resistant.
2. The main body of the chassis adopts 2.0MM thick cold-rolled plate, which has strong acid and alkali corrosion resistance and long service life.
3. The bottom layer of galvanized rust, surface fluorocarbon paint spray, rain, corrosion resistance, anti-aging for indoor and outdoor all kinds of places.
4. Designed with good heat dissipation and cooling methods, high system stability under high temperature and humid working environment.
5. Appearance patents with independent intellectual property rights have advanced design concepts in the industry, there is no special use environment requirements.
Features
1.Smooth design lines, simple and elegant, with black imported tempered acrylic, low profile luxury, stylish, durable, wear-resistant
2. The main body of the chassis adopts a 2.0MM thick cold-rolled plate, which has strong acid and alkali corrosion resistance and long service life.
3.The bottom layer of galvanized rust, surface fluorocarbon paint spray, rain, corrosion resistance, anti-aging for indoor and outdoor all kinds of places
4. Designed with good heat dissipation and cooling methods, high system stability under high temperature and humid working environment.
5. Appearance patents with independent intellectual property rights have advanced design concepts in the industry, there is no special use environment requirements.
